FBI Photo B7

Evidence media

Derived official PDF page render: FBI Photo B7

Derived page render from the official PDF. The page shows a redacted monochrome still-image sheet with a central reticle and the lower-left displayed timestamp 12/31/99 18:10:02; the release description says the system date/time was not set, so that overlay is not treated as the incident time.

Extracted embedded image object from FBI Photo B7

Extracted image object from the same official PDF. It isolates the underlying 1280 × 960 raster: a grainy grayscale frame with redaction blocks, one compact dark unresolved feature above/right of the reticle center, and a separate smaller dark dot below/right of center. The extracted raster does not materially change the source content visible in the page render.

Investigation reading

This Release 01 item is a one-page FBI PDF containing a single still image. The release description says the FBI submitted the image to AARO as a report of an unidentified anomalous phenomenon derived from a U.S. military system in 2025. It also says the original imagery was altered with redactions before submission, that no accompanying mission report was provided, and that the operator reported being unable to positively identify the UAP.

The file should be read as a still-image evidence item, not as a complete incident packet. The visible image gives a frame, a reticle, redactions, a timestamp overlay, and two dark unresolved features. It does not provide motion, range, sensor calibration, platform identity, environmental context, or the missing mission report. This page therefore preserves the visual/provenance reading and keeps the status as a graph investigation draft, not a finding.

What the file appears to contain

The PDF is a 607,218-byte, one-page document with one embedded RGB image at 1280 × 960 pixels. PDF metadata identifies it as “B7 FBI Photo.” The page text layer is effectively empty for investigative purposes; Frontier OCR preserves only the page marker and the timestamp text 12/31/99 18:10:02.

Visual inspection of the extracted image shows a noisy monochrome sensor-style frame with a central white reticle. The horizontal reticle is labeled with 5, 10, and 15 markings on both sides, while the vertical reticle has tick marks without visible numeric labels. Multiple black rectangular blocks and adjacent gray mask-like patches obscure portions of the frame. These are consistent with release redactions or overlay masking, and they limit what can be read from the still.

The most prominent unresolved feature is a compact dark irregular shape above and to the right of the reticle center. A faint slanted darker extension or smear appears near it, but the image is too noisy and too small to establish a reliable outline. A separate smaller dark dot or speck is visible below the reticle and slightly right of center. The official narrative description says a dark object “consistent in appearance with a helicopter” is visible in the upper-right quadrant and that a second, smaller, dark circular object is below the reticle. In this draft, that phrasing is treated as release-description language, not an independent identification. From this single still, the visible features remain unresolved.

The displayed date 12/31/99 should not be treated as the incident date. The release description states that the date in the image is incorrect because the system date/time was not set.

Source custody and provenance

The official media endpoint was not directly retrievable during this check, returning access-control errors to a direct request. The release-file copy used here matches the recorded SHA-256 hash and preserves the official URL as the source pointer.

Graph context

The graph has two exact document records for this item: the PDF asset record and the Release 01 manifest/CSV record. The asset record points to the official PDF URL and carries the verified SHA-256. The release-record layer is the source of the CSV-row context and release-description wording.

The semantic extraction currently lists 22 claim records, 14 entity mentions, 4 sensor-event records, and 0 table rows for this item. The sensor-event records come from source phrases such as “still image” and “military system.” They should be treated as media/platform context, not as independent multi-sensor corroboration. The graph also surfaces related B-series and adjacent release records as navigation context only; this page does not treat those links as proof of a shared incident.

There is a provenance cleanup lead around row/version metadata. Current Open Sky release metadata ties B7 to row 133, while one manifest-description record surfaces older or derived row numbering and the release-record layer supplies Late 2025 / Western United States metadata that is not present in the asset-level fields. Those fields should be reconciled against the current official CSV before cross-record analysis.

Leads to check

  • Locate any less-redacted or original frame sequence, not just the released still.
  • Determine the sensor/platform, reticle scale, field of view, and whether the visible markings have known units.
  • Locate the missing mission report or operator notes, if they exist outside this release item.
  • Compare adjacent frames or video, if available, to test whether the upper-right feature or lower dot persists, moves, or disappears as an imaging artifact.
  • Reconcile current CSV row 133 against any older manifest-derived row references and the Late 2025 / Western United States metadata.
  • Check ordinary image-quality explanations first: redaction artifacts, compression, sensor noise, focus, motion blur, timestamp/system-clock error, and scale ambiguity.

Lead check notes

  • Checked: PDF/container review found one page, one embedded 1280 × 960 RGB image, and no embedded attachments. The derived page render and extracted raster show the same redacted still content.
  • Blocked: Less-redacted imagery, the original frame sequence, adjacent video, platform/sensor settings, reticle scale, the missing mission report, and operator notes are not present in the released PDF or the current release-file record.
  • Partial: Provenance cleanup remains open. B7 is stable by title, official URL, and verified SHA-256, while release metadata can surface row 133 alongside older release-table or manifest-style row references such as 136; the Late 2025 / Western United States fields appear at the release-record layer and still need manifest-history reconciliation.
  • Needs external source: Ordinary image-quality and prosaic checks — sensor blemish, compression or redaction artifact, distant aircraft, bird, balloon, debris, weather, illumination, and line-of-sight — require unredacted imagery, collection geometry, frame sequence, and environmental records before any resolution claim.

Deep investigation — graph + web reconnaissance

Source reread

The source file re-check confirms the existing custody baseline: a 607218-byte, one-page PDF with SHA-256 4f3122c323c6c0b6ef1bb12cefc623d7488b03fe1c5161f4ea4e111b91347684. PDF metadata labels it B7 FBI Photo; the file is copy-restricted/encrypted, has a 640 × 480 pt page, and contains one embedded 1280 × 960 RGB image. Text extraction is not useful for the body of the file; the only OCR-bearing source text is the page marker and the displayed timestamp 12/31/99 18:10:02.

Visual review of the embedded raster supports a cautious reading only. The image is a noisy grayscale instrument-overlay frame with a central reticle, horizontal 5 / 10 / 15 scale marks, multiple black and gray redaction or mask blocks, a compact dark unresolved feature above/right of reticle center, and a separate smaller dark dot below/right of center. The still does not expose the reticle units, platform, sensor mode, range, motion, direction of travel, or environmental setting. The release description says the system clock was not set, so the visible 12/31/99 timestamp remains a display artifact rather than an incident date.

Graph connections

The graph currently resolves B7 through the exact official asset record plus the current Release 01 row record. The stable asset identifiers are the title FBI Photo B7, official PDF URL, row 133, 607218-byte file size, and the verified SHA-256 above. The semantic layer attached to this asset contains 22 machine-extracted claims, 14 entity mentions, and 4 sensor-event records. The claim/entity samples are mostly source-custody and description terms — FBI, AARO, 2025, still image, military system, and the operator statement that they were unable to positively identify the object. The sensor-event records are STILL IMAGE / military system cues; they are media/platform context, not independent radar, IR, telemetry, or multi-sensor corroboration.

The graph also exposes provenance-cleanup issues rather than new case evidence: the current row record carries Late 2025 and Western United States, the asset's manifest-description chunk can still mention older row 136, and a stale neighboring row can point B7's file hash or URL at a NASA Apollo transcript row while another stale record points the B7 row at a B4 file URL. Those are row/version reconciliation leads only. A secondary UFO-USA GitHub Markdown conversion is present as a derived coverage/search layer, not a replacement source of record. No CANDIDATE_CROSSLINK relationship was returned for the exact B7 asset in this check.

External provenance and web context

Official-source probes remained access-limited: direct WAR.GOV requests for the PDF, thumbnail, landing page, and CSV returned 403 responses during this check. That does not invalidate the cached Open Sky release-file copy because its bytes match the recorded official-primary SHA-256. Internet Archive CDX did list exact-URL application/pdf captures for the B7 WAR.GOV PDF on 20260508 and later, but the public Wayback availability endpoint did not surface an available snapshot in the same probe; those archive records are therefore useful provenance leads, not a substitute for hash-verified source custody until the archived file is fetched and compared.

DVIDS did not return a usable B7 search result in this check, and AARO/Defense search probes were also access-limited. No released mission report, raw video, frame sequence, platform log, or sensor metadata was located from the official/agency reconnaissance paths checked here.

Prosaic checks and open leads

Because B7 has only a broad Late 2025 / Western United States row-level context and no exact time, coordinates, platform track, look direction, altitude, or weather, ordinary astronomy/weather/launch/satellite correlation is not meaningful yet. The first prosaic lanes remain image-quality and release-processing issues: redaction masks, compression/resampling, low contrast, sensor noise, blur or smear, reticle-scale ambiguity, and the possibility that either visible dark mark is an artifact or an ordinary distant object seen without enough geometry to classify.

Follow-up priority is source recovery, not conclusion-writing: locate the missing mission report or operator notes, recover less-redacted imagery or the original frame sequence, identify the collection platform/sensor and reticle units, reconcile row/version drift against the current official CSV, and compare adjacent B-series items only after a source-level reason for a shared incident is established.

Audit note

This section does not create a finding, hypothesis, or resolution. It separates source-visible facts, machine-extracted graph context, provenance-cleanup leads, and blocked prosaic checks. The item remains a redacted still-image evidence page requiring human review.

Limits

This page is based on one redacted still image plus release metadata. It does not include the original unredacted imagery, a mission report, platform/sensor logs, range data, motion tracking, weather context, satellite/launch checks, or independent witness corroboration. The visible dark features cannot be measured or identified from the still alone. No resolution, hypothesis, or finding is asserted.

Sources

  • WAR.GOV/PURSUE Release 01 official PDF: FBI Photo B7
  • Open Sky release-file copy: war-gov-fbi-photo-b7-ccd932b4
  • Release manifest context: FBI Photo B7, current CSV row 133, FBI, PDF, redacted still image submitted to AARO.
  • Verified file hash: 4f3122c323c6c0b6ef1bb12cefc623d7488b03fe1c5161f4ea4e111b91347684
